CueSee® CO-OXPT
Unique quality control for CO-oximeters with real hemoglobin derivatives performing like patient samples.
Description
Eurotrol has revolutionized quality control for CO-oximeters by developing CueSee CO-OX PT with real hemoglobin derivatives performing like patient samples. Packaged in the ACU-Drop® II, this innovative, dual-chambered device keeps the oxyhemoglobin separated from the methemoglobin to provide a long shelf-life. This product is:
- Available in 6 clinically relevant levels.
- Compatible with all common CO-oximeters.
- Ideal for quality control, method comparisons, AMR validations and proficiency testing.
Intended Use
Eurotrol CueSee® CO-OX PT is an unassayed, real hemoglobin control intended for professional use in the verification of the precision and accuracy of CO-oximeters measuring total hemoglobin (tHb) and fractions of Hb-derivatives Oxyhemoglobin (FO2Hb), Carboxyhemoglobin (FCOHb) and Methemoglobin (FMetHb). The purpose of this quality control is to check wavelength and absorbance calibration and other performance related characteristics.
Analytes
ARTICLE CODE
249.001.001
249.002.001
249.003.001
249.004.001
249.005.001
249.006.001
Level 1
Level 2
Level 3
Level 4
Level 5
Level 6
tHb
17.2 - 18.8
9.8 - 11.2
11.2 - 12.8
12.8 - 14.2
14.2 - 15.8
15.8 - 17.2
g/dL
O2Hb
85.00 - 100.00
75.00 - 85.00
65.00 - 75.00
55.00 - 65.00
45.00 - 55.00
35.00 - 45.00
%
COHb
2.50 - 7.50
7.50 - 12.50
12.50 - 17.50
17.50 - 22.50
22.50 - 27.50
27.50 - 32.50
%
MetHb
0.00 - 7.50
7.50 - 12.50
12.50 - 17.50
17.50 - 22.50
22.50 - 27.50
27.50 - 32.50
%
All ranges per analyte are target ranges for manufacturing of the product. See actual value sheets with lot specific values, which may vary in range widths and mean values due to instrument chosen for value assignments.
Details
Container
Filling
Box
Storage Temperature
Shelf-life
ACU-Drop® II
2.0 ± 0.1 mL
1 per Box
Unopened
2 - 8 °C
Opened
2 - 8 °C
Unopened
N/A
Opened
15 minutes
Documents
Tutorials
How to use the ACU-Drop® II
ACU-Drop® II is an innovative, dual chambered, device that keeps various fractions separated, preventing reactions between components of the desired matrix. In this tutorial we will show how to use the ACU-Drop® II by sampling from the dropper tip or with a syringe.
start tutorial
Advantages and Principles of CueSee® CO-OX
CueSee® CO-OX is a quality control material for CO-oximetry testing based on real hemoglobin derivatives. This tutorial will explain the great benefits of such a matrix that has the same sensitivity as patient samples.
